| Types | Diagram | Density kg/m3 | Nominal Thermal Conductivity λ [W/(m·K)] | Thickness mm | Thermal Resistance R m2 ·k/W | Thermal Conductivity [W/(m2 ·K)] |
| PUR/PIR Sandwich Panel |  | 38-43k | 0.024 | 50 | 2.23 | 0.45 |
| 75 | 3.28 | 0.31 | ||||
| 100 | 4.32 | 0.23 | ||||
| 150 | 6.4 | 0.16 | ||||
| 200 | 8.42 | 0.12 | ||||
| 250 | 11.02 | 0.09 | ||||
| Note: The thermal conductivity is suitable for most projects but not for regions with hot summers and warm winters. | ||||||
| Sheet Specification | Width | 450-1120mm |
| Thickness | 30~250mm | |
| Length | Transportation Limitations | |
| Panel Specification | Material | Colored Coated Steel Plate、Galvalume Steel Sheet 、Stainless Steel Plate |
| Thickness | 0.4 ～ 0.8mm | |
| Coating | PE 、HDP、SMP、PVDF | |
| PIR | Fire Rating | B1 GR (Oxygen Index ≥ 30%) |
| Closed Cell Rate | ≥ 97% | |
| Water Absorption Rate | ≤ 3% | |
| Thermal Conductivity | 0.019-0.024 | |
| Heat Resistance Range | -196℃ +160℃ | |
| Compressive Strength | ≥ 120kpa |
